UTP cable, 2 pairs, XS series, category 5е, PVC

UTP cable, 2 pairs, XS series, category 5е, PVC

Product Code: TWT-5EUTP2-XS

UTP cable, 2 pairs, XS series, category 5е, PVC
Model range

UTP cable, 2 pairs, XS series, category 5е, PVC

Two pairs cable is a budget solution for voice, fire alarm, and security cabling, connection of xDSL modems, and Ethernet network (10Base-T and 100Base-T which use two pairs for connection) cabling.

Specification Value
Jacket Color Grey
Jacket Material PVC (polyvinyl chloride)
Insulation Material HDPE (high density polyethylene)
Conductor Type Solid
Conductor Gauge 24 AWG
Nominal Velocity Propagation (NVP) 66%
Cable Diameter 4.0 mm
Cable Length per Reel 305 m
Operating Temperature -20 ºC to 75 ºC
Color Coding
Pair Color Pair Color
1 blue/white-blue 2 orange/white-orange
Product descriptions are listed according to the available information at the time of publication. Product specifications can be changed without advanced notification. More detailed and exact information can be obtained from the official partners and distributors of LANMASTER.

Model range (1)

Code Name
TWT-5EUTP2-XS UTP cable, 2 pairs, XS series, category 5е, PVC Add to list
