Shielded category 5e cable is designed for digital and analog signals transmission on frequencies below 100 MHz.
Polyethylene jacket has high rigidity against low temperature, high humidity, and solar radiation what makes the cable suitable for outdoor installations.
The cable comprises four twisted pairs of solid copper conductors with overall foil shield under a single jacket.
Specification
Value
Jacket Color
Black
Jacket Material
PE (polyethylene)
Insulation Material
HDPE (high density polyethylene)
Conductor Type
Solid
Conductor Gauge
24 AWG
Nominal Velocity Propagation (NVP)
66%
Cable Diameter
6.2 mm
Cable Length per Reel
305 m
Operating Temperature
-20 ºC to 75 ºC
Color Coding
Pair
Color
Pair
Color
1
blue/white-blue
3
orange/white-orange
2
green/white-green
4
brown/white-brown
Product descriptions are listed according to the available information at the time of publication. Product specifications can be changed without advanced notification. More detailed and exact information can be obtained from the official partners and distributors of LANMASTER.
Model range (1)
Code
Name
TWT-5EFTP-XS-OUT
FTP cable, 4 pairs, XS series, category 5е, outdoor, PE
