Finger bracket kit for 800 mm wide LANMASTER DCS cabinets, 2 pcs. in the kit, black

Finger bracket kit for 800 mm wide LANMASTER DCS cabinets, 2 pcs. in the kit, black

Product Code: LAN-DC-CB-xxUx8-PF/y

Finger bracket kit for 800 mm wide LANMASTER DCS cabinets, 2 pcs. in the kit, black
Model range

Vertical cable finger bracket designed to distribute cable flows in 800 mm wide LANMASTER DC series cabinets.

Management of cables is carried out with "fingers" located in 1U increments. The fingers made of reinforced plastic and provided cable support at the each RMU level. The rounded surface of the "fingers" protects the cables’ jacket from damage and provides the required bending radius.

The bracket is installed on mounting rails in the space between the rails and the side panels of 800 mm wide DC series cabinets and fastened with cage nuts in the corresponding holes.

In the installed position, the brackets do not block the holes for cable entries in the mounting rails, and do not hide the height unit marks.

Two types of finger managers are available: 106 mm and 169 mm deep.

The kit includes two finger brackets and the necessary fasteners for installation.

Made of steel and reinforced plastic.

Product descriptions are listed according to the available information at the time of publication. Product specifications can be changed without advanced notification. More detailed and exact information can be obtained from the official partners and distributors of LANMASTER.

Model range (4)

Code Name
LAN-DC-CB-42Ux8-PF/L 42U heigh and 169 mm deep finger bracket kit for 800 mm wide LANMASTER DCS cabinets, 2 pcs. in the kit, black Add to list
LAN-DC-CB-42Ux8-PF/S 42U heigh and 109 mm deep finger bracket kit for 800 mm wide LANMASTER DCS cabinets, 2 pcs. in the kit, black Add to list
LAN-DC-CB-48Ux8-PF/L 48U heigh and 169 mm deep finger bracket kit for 800 mm wide LANMASTER DCS cabinets, 2 pcs. in the kit, black Add to list
LAN-DC-CB-48Ux8-PF/S 48U heigh and 109 mm deep finger bracket kit for 800 mm wide LANMASTER DCS cabinets, 2 pcs. in the kit, black Add to list
