TWT RG11U 75 Ohm Coaxial Cable, CCS, 96*0.16 mm AL braid, PE, outdoor with messenger wire, black, 305 m

Product Code: TWT-RG11-CS96/3-OTR

TWT RG11U 75 Ohm Coaxial Cable, CCS, 96*0.16 mm AL braid, PE, outdoor with messenger wire, black, 305 m

TWT RG11 trunk cable with messenger wire is used as part of distribution television networks when organizing aerial cable links between buildings.

Center conductor: copper clad steel wire (CCS), solid

Center conductor insulation: low density expanded (foamed) polyethylene

Shield: aluminum laminated foil and aluminum braid

Outer jack: PE (polyethylene)

Messenger wire: Ø2,5 mm steel wire

Color: black

Packaging: 305 m on a reel

Physical characteristics of the cable:


Characteristics Value
Center conductorDiameter1.63+/-0.01 (14AWG)
MaterialCopper Clad Steel (CCS)
Conductor insulationDiameter7.20+/-0.13 mm
Centering>=90 %
Shield№1MaterialAluminum foil
Shield density100%
Thickness0,16 mm
№2Number of wires 6/16
Shield density60%
MaterialAluminum
Cable diameter by shield7,91 mm
JacketDiameter 10.20±0.10 mm
MaterialPE
Dielectric strength of the outer jacket 3000Vac
ColorBlack
Temperature Operatingfrom -40°С to +70°С
WeightOf 1 km of cable122 kg


Electrical (transmission) characteristics of the cable:

Characteristics >Value
Wave impedance 75±3 Ohm
Electrical capacitance 53±2 pF/m
Nominal velocity propagation 83 %
Return loss at 5 - 1000 MHz ≥20 dB
Attenuation, dB/100 m (20°С) 55 MHz 0,96
211 MHz 1,9
450 MHz 2,75
600 MHz 3,18
870 MHz 4,06
1000 MHz 4,35
Product descriptions are listed according to the available information at the time of publication. Product specifications can be changed without advanced notification. More detailed and exact information can be obtained from the official partners and distributors of LANMASTER.
