Cable comprises 10 pairs of solid copper conductors.
It is compliance with category 5e.
Each conductor is covered with HDPE (high density polyethylene) insulation.
Two conductors are twisted with specially selected step in a single twisted pair. Twisted pairs are gathered around a strength core element, wrapped with polyethylene tape, and covered with a single PVC jacket.
There is a ripcord under the cable jacket for termination process convenience.
The cable is delivered on reels by 305 meters length. Other construction lengths are available by order.
Specification
Value
Jacket Color
Blue
Jacket Material
PVC
Insulation Material
HDPE (high density polyethylene)
Conductor Type
Solid
Conductor Gauge
24 AWG
Nominal Velocity Propagation (NVP)
66%
Cable Diameter
15.8 mm
Cable Length per Reel
305 m
Operating Temperature
-20 ºC to 75 ºC
Regulatory Certifications
UL VERIFIED
Regulatory Compliance
TIA/EIA 568.2-D cat. 5; ISO/IEC 11801
Color Coding
Pair
Color
Pair
Color
1
white - blue
26
white/brown - blue
2
white - orange
27
white/brown - orange
3
white - green
28
white/brown - green
4
white - brown
29
white/brown - brown
5
white - grey
30
white/brown - grey
6
red - blue
31
red/grey - blue
7
red - orange
32
red/grey - orange
8
red - green
33
red/grey - green
9
red - brown
34
red/grey - brown
10
red - grey
35
red/grey - grey
11
black - blue
36
black/orange - blue
12
black - orange
37
black/orange - orange
13
black - green
38
black/orange - green
14
black - brown
39
black/orange - brown
15
black - grey
40
black/orange - grey
16
yellow - blue
41
yellow/blue - blue
17
yellow – orange
42
yellow/blue - orange
18
yellow - green
43
yellow/blue - green
19
yellow - brown
44
yellow/blue - brown
20
yellow - grey
45
yellow/blue - grey
21
purple - blue
46
purple/green - blue
22
purple - orange
47
purple/green - orange
23
purple - green
48
purple/green - green
24
purple - brown
49
purple/green - brown
25
purple - grey
50
purple/green - grey
Note the color coding for 26-50th pairs!
Product descriptions are listed according to the available information at the time of publication. Product specifications can be changed without advanced notification. More detailed and exact information can be obtained from the official partners and distributors of LANMASTER.
Model range (1)
Code
Name
TWT-5EUTP50
TWT UTP, 50 pairs, category 5e, PVC, 305 meters on a reel
