TWT UTP cable, single pair, cat. 5E, PVC, grey, 305 m

TWT UTP cable, single pair, cat. 5E, PVC, grey, 305 m

Product Code: TWT-5EUTP1-GY

TWT UTP cable, single pair, cat. 5E, PVC, grey, 305 m
Model range

Single pair cables are budget solution for voice, fair alarm, and security cabling. Also, they can be used as cross wires.

The cable comprises two solid copper 24 AWG conductors. Each conductor is insulated with HDPE (high density polyethylene). Those two conductors are twisted with specially selected step in a single twisted pair and covered with PVC jacket.

Specification Value
Jacket Color Grey
Jacket Material PVC (polyvinyl chloride)
Insulation Material HDPE (high density polyethylene)
Conductor Gauge, single 24 AWG
Conductor Type Solid
Cable Diameter 3 mm
Operating Temperature -20 ºC to +75 ºC
Cable Length per Box 305 m
Regulatory Certifications ETL VERIFIED, UL, CSA
Regulatory Compliance TIA/EIA 568-D.2 cat. 5e
Product descriptions are listed according to the available information at the time of publication. Product specifications can be changed without advanced notification. More detailed and exact information can be obtained from the official partners and distributors of LANMASTER.

Model range (1)

Code Name
TWT-5EUTP1-GY TWT UTP cable, single pair, cat. 5E, PVC, grey, 305 m Add to list
