The cable comprises 10 pairs of solid copper conductors. It is compliance with category 5e.
Each conductor is covered with HDPE (high density polyethylene) insulation. Two conductors are twisted with specially selected step in a single twisted pair.
The twisted pairs are gathered around a filler rope, wrapped in laminated foil and covered with a single PVC jacket.
There is a ripcord under the cable jacket for termination process convenience and a drain wire for continuous grounding under the foil layer.
The cable is delivered on reels by 305 meters length. Other construction lengths are available by order.
Specification
Value
Jacket Color
Blue
Jacket Material
PVC (polyvinyl chloride)
Insulation Material
HDPE (high density polyethylene)
Conductor Type
Solid
Conductor Gauge
24 AWG
Nominal Velocity Propagation (NVP)
66%
Cable Diameter
8.3 mm
Cable Length per Reel
305 m
Operating Temperature
-20 ºC to 75 ºC
Regulatory Certifications
UL
Regulatory Compliance
TIA/EIA 568.2-D cat. 5; ISO/IEC 11801; EN50173
Color Coding
Pair
Color
Pair
Color
1
white - blue
6
red - blue
2
white - orange
7
red - orange
3
white - green
8
red - green
4
white - brown
9
red - brown
5
white - grey
10
red - grey
Product descriptions are listed according to the available information at the time of publication. Product specifications can be changed without advanced notification. More detailed and exact information can be obtained from the official partners and distributors of LANMASTER.
Model range (1)
Code
Name
TWT-5EFTP10
TWT FTP cable, 10 pairs, category 5e, PVC, 305 meters on a reel
