Straight splice bar for steel ladder, gray

Straight splice bar for steel ladder, gray LAN-LTS-CNT-GY: specifications, description, purpose and use in structured cabling, data center and LANMASTER infrastructure projects.
LAN-LTS-CNT-GY

Purpose:

  • straight splicing of two LAN-LTS-ZL profiles.


Features:

  • quick and easy installation,
  • 2 pcs. per splice.

Frequently Asked Questions

What is the LAN-LTS-CNT-GY straight connector used for?

The connector joins two LAN-LTS-ZL longitudinal profiles of the steel ladder tray end to end, extending the profile in a straight line. Installation is quick and does not require complicated operations.

How many LAN-LTS-CNT-GY connectors are needed for one profile joint?

Two connectors are required for one joint of two LAN-LTS-ZL profiles. Order twice as many connectors as there are joints on the route.

Which fasteners should be used to install the connector?

Use the LAN-LTS-FIXSET screw and nut set to fasten the elements of the steel ladder tray. The set is supplied separately from the connector.

How does the LAN-LTS-CNT-GY straight connector differ from the angle connector and the T-joint bracket?

The LAN-LTS-CNT-GY straight connector extends the profile in a straight line. The LAN-LTS-L100-GY angle connector joins two LAN-LTS-ZL profiles to each other, and the LAN-LTS-BTF-GY bracket makes a T-joint of two profiles.

Is the LAN-LTS-CNT-GY connector suitable for an aluminium ladder tray?

No. The item belongs to the accessory series for the LAN-LTSxxx-GY steel tray. For the LAN-LTAxxx aluminium tray use accessories of the LAN-LTA series, for example the LAN-LTA-CNT straight connector.

Is additional bonding required at the joints of a steel ladder tray?

A steel tray is part of a metal cable route, so check the project and the site regulations: they define whether the mechanical connection of the sections is sufficient or a separate bonding jumper is required at every joint. If a jumper is specified, install it at every joint so that the grounding path stays continuous along the whole route.

Didn’t find an answer to your question?

Package dimensions and weight

Single item

Product code Unit length × width × height (mm) Weight (kg) Volume (m3)
LAN-LTS-CNT-GY pcs 180 × 25 × 40 0.205 0.00018

Package

Product code Unit length × width × height (mm) Weight (kg) Volume (m3)
LAN-LTS-CNT-GY box 20 × 110 × 230 10.1 0.000506

Product Codes (1)

  • Straight splice bar for steel ladder, gray
Specifications are subject to change without notice. For the most current information, consult LANMASTER or an authorized LANMASTER partner/distributor.
