TWT UTP cable, 25 pairs, Cat. 5, PVC, 305 meters per drum

Product Code: TWT-5UTP25

TWT UTP cable, 25 pairs, Cat. 5, PVC, 305 meters per drum

The cable consists of 25 pairs of solid copper conductors.
Conductor diameter is 24AWG.
Each conductor is enclosed in HDPE (high-density polyethylene) insulation.

Meets the requirements of Category 5.

Two conductors, twisted with a specially selected step, make up one twisted pair.
Twisted pairs are assembled around the central element, wrapped in a plastic film and enclosed in a common PVC jacket.

To facilitate cable termination, a rip cord is included under the jacket.

The cable is supplied on 305 meters drums. Other construction lengths can be supplied on request.

Characteristic Value
Jacket color Blue
Jacket material PVC (polychlorinated vinyl chloride)
Insulation material HDPE (High Density Polyethylene)
Conductor diameter 24 AWG
Conductor Type Solid
Insulation thickness 0.24 mm
Cable diameter 13.8 mm
Fire safety rating CMR (vertical tray cable)
NVP 66%
Frequency range 1-100 MHz
Operating temperature range -20 °C / +75 °C
Number of meters per drum 305 m
Laboratory certification UL
Compliant with TIA/EIA 568-A cat,5 standards; ISO/IEC 11801; EN 50173
Support for the following applications:
  • Speech
  • Т1
  • 10BASE-T, 100BASE-T
  • Token Ring 4/16 Mb/s
  • АТМ 155 Mb/s, TP-PMD 100 Mb/s
  • 100VG-AnyLAN
  • 100 Mbps CDDI


Color coding:
Pair 1 White — Blue Pair 13 Black — Green
Pair 2 White — Orange Pair 14 Black — Brown
Pair 3 White — Green Pair 15 Black — Gray
Pair 4 White — Brown Pair 16 Yellow — Blue
Pair 5 White — Grey Pair 17 Yellow — Orange
Pair 6 Red — Blue Pair 18 Yellow — Green
Pair 7 Red - Orange Pair 19 Yellow — Brown
Pair 8 Red — Green Pair 20 Yellow — Gray
Pair 9 Red — Brown Pair 21 Purple — Blue
Pair 10 Red — Grey Pair 22 Purple — Orange
Pair 11 Black — Blue Pair 23 Purple — Green
Pair 12 Black — Orange Pair 24 Purple — Brown

Pair 25 Purple — Gray

Electrical characteristics of the cable:

CharacteristicValue
Impedance 100 +/- 15 Ohm
Maximum capacitance 17.1 nF/305m
Conductor resistance 28.6 Ohm/305m
Unbalance resistance 5%
Pair capacitance to ground unbalance 330 pF/100m
Skew delay 35 ns/100m
Nominal velocity propagation rate 66%
