TWT UTP cable, 10 pairs, category 5e, LSZH, 305 meters, white

TWT UTP cable, 10 pairs, category 5e, LSZH, 305 meters, white

Product Code: TWT-5EUTP10-LSZH

TWT UTP cable, 10 pairs, category 5e, LSZH, 305 meters, white
Model range

The multipairs unshielded cable is designed for transmission of data, voice and CCTV signals on frequencies below 100 MHz. The cable comprises 10 pairs of solid copper conductors. Outer jacket is LSZH.

Each conductor is covered with HDPE (high density polyethylene) insulation. Two conductors are twisted with specially selected step in a single twisted pair.

The twisted pairs are gathered around a core element and covered with a single LSZH jacket.

There is a ripcord under the cable jacket for termination process convenience.

The cable is delivered on reels by 305 meters length. Other construction lengths are available by order.

Specification Value
Jacket Color White
Jacket Material LSZH (low smoke, zero halohen)
Insulation Material HDPE (high density polyethylene)
Conductor Type Solid
Conductor Gauge 24 AWG
Nominal Velocity Propagation (NVP) 66%
Cable Diameter 8.5 ±0.2 mm
Cable Length per Reel 305 m
Operating Temperature -20 ºC to 75 ºC
Regulatory Certifications UL VERIFIED
Regulatory Compliance TIA/EIA 568.2-D cat. 5; ISO/IEC 11801; EN50173
Color Coding
Pair Color Pair Color
1 white - blue 6 red - blue
2 white - orange 7 red - orange
3 white - green 8 red - green
4 white - brown 9 red - brown
5 white - grey 10 red - grey
Product descriptions are listed according to the available information at the time of publication. Product specifications can be changed without advanced notification. More detailed and exact information can be obtained from the official partners and distributors of LANMASTER.
