TWT UTP cable, 4 pairs, category 5e, for patch-cords (stranded), PVC, 305 meters, grey

TWT UTP cable, 4 pairs, category 5e, for patch-cords (stranded), PVC, 305 meters, grey

Product Code: TWT-5EUTP-PT-GY

TWT UTP cable, 4 pairs, category 5e, for patch-cords (stranded), PVC, 305 meters, grey
Model range

The cable comprises 4 pairs of stranded copper conductors. Conductor gauge is 24AWG.
Each conductor is covered with HDPE (high density polyethylene) insulation.

Two conductors are twisted with specially selected step in a single twisted pair.

The cable comprises four twisted pairs of solid copper conductors under a single PVC jacket.

Specification Value
Jacket Color Grey
Jacket Material PVC
Insulation Material HDPE (high density polyethylene)
Conductor Type Stranded (7 wires / 0.18 ± 0.01 mm)
Conductor Gauge 24 AWG
Cable Diameter 5.1 ±0.2 mm
Nominal velocity propagation (NVP) 66% at 100 MHz
Cable Length per Box 305 m
Operating Temperature -20 ºC to +75 ºC
Regulatory Certifications ETL VERIFIED
Regulatory Compliance TIA/EIA 568-D.2 cat. 5E,
ISO/IEC 11801-1:2017,
EN 50173
Product descriptions are listed according to the available information at the time of publication. Product specifications can be changed without advanced notification. More detailed and exact information can be obtained from the official partners and distributors of LANMASTER.

Model range (1)

Code Name
TWT-5EUTP-PT-GY TWT UTP cable, 4 pairs, category 5e, for patch-cords (stranded), PVC, 305 meters, grey Add to list
