19" modular angled patch panel with shutters, shielded, 24 port, 1U

The modular patch panels are designed for installation of Keystone modules (see compatibility items).

The distinctive feature of the panel is the angled design, which provides a small bending radius of the patch cords connected to the patch panel. As a result, the use of such patch panels is recommended when creating category 6 and 6A horizontal and backbone subsystems of SCS.

Angled patch panels eliminate the need for front side horizontal patch cord managers and make the most of the free space in the closet.

TAKE ATTENTION!!!!! When installing these patch panels in 19-inch cabinets equipped with doors, the mounting rails of the latter should be installed at a depth of at least 120 mm from the inner surface of the door. Otherwise, patch cords coming out of the panel will prevent the cabinet door from closing.

There are areas for additional port labels on the front side of the panel. The modules are flush-mounted. The openings for the modules from the front are closed with plastic folding shutters to protect the socket from dust.

A comb with metal tabs for each module provides reliable connection ground system and shielded (STP) modules installed in the panel. The package also includes a grounding conductor. There is a retention bar with holes for easy installation and additional fastening of the incoming cables on the edge of the rear side of the panel.
