Aisle containment system roof section for DC series cabinets
Aisle roof section for DC series cabinets covers the space between two rows of cabinets to form an isolated aisle.
The panels are transparent. The frame is made of steel, the roof panel is made of transparent plexiglass.
Turnable roofs are equipped with an electromagnetic lock to ensure access of the fire extinguishing agent inside the aisle in case of a fire alarm. The roof structure has a U-shaped frame so to not prevent access to equipment located in the upper mounting units of the cabinet.
The roof section can be 300, 600, or 800 mm wide depending on the width of the cabinets in a row and the presence of in-row air conditioners. The basic roof is used for an aisle width of 1200 mm, sections of other lengths can be made on request.
Frequently asked questions and answers
What is the LAN-DC-RFP-12xx-yy roof designed for?
This corridor section roof closes the space between two rows of cabinets, forming an isolated corridor.
Can you see through the roof?
Yes, the panels are light-transmitting: the roof is made of transparent acrylic on a steel frame.
How does the roof interact with the fire suppression system?
Hinged versions are fitted with an electromagnetic lock: when a fire alarm triggers, the lock opens, letting the extinguishing agent reach the corridor.
Does the roof block access to the top units of the cabinets?
No, the roof has a P-shaped profile that does not block access to equipment in the cabinet's top units.
What width and design variants is the roof available in?
The section width is 300, 600, or 800 mm (depending on the cabinet widths in the row and whether in-row air conditioners are present); solid (FX) and hinged with an electric lock (OP) designs are available; the standard corridor length is 1200 mm.
Package dimensions and weight
Single item
| Product code | Unit | length × width × height (mm) | Weight (kg) | Volume (m3) |
|---|---|---|---|---|
| LAN-DC-RFP-12x3-FX | pcs | 1480 × 420 × 170 | 0.033 | 0.105672 |
| LAN-DC-RFP-12x6-FX | pcs | 150 × 750 × 180 | 15 | 0.02025 |
| LAN-DC-RFP-12x8-FX | pcs | 146 × 102 × 280 | 21 | 0.00417 |
| LAN-DC-RFP-12x6-OP | pcs | 146 × 720 × 200 | 21 | 0.021024 |
| LAN-DC-RFP-12x8-OP | pcs | 145 × 102 × 300 | 31 | 0.004437 |
Product Codes (5)
-
1200 mm length aisle 600 mm wide roof section for LANMASTER DC cabinets, turnable, with electromagnetic lock
-
1200 mm length aisle 800 mm wide roof section for LANMASTER DC cabinets, turnable, with electromagnetic lock
