TWT 75 Ohm RG6U Coaxial cable, CCS, 48*0.12 mm AL braid, PVC, white, 100 m

TWT 75 Ohm RG6U Coaxial cable, CCS, 48*0.12 mm AL braid, PVC, white, 100 m

Product Code: TWT-RG6U-CS48/1-WH

TWT 75 Ohm RG6U Coaxial cable, CCS, 48*0.12 mm AL braid, PVC, white, 100 m
Model range

It is used for satellite and cable TV networks, analog video surveillance. Used for indoor installation.

Center conductor: copper clad steel wire (CCS), solid

Center conductor insulation: low density expanded (foamed) polyethylene

Shield: aluminum laminated foil and aluminum braid

Outer jack: PVC (polyvinyl chloride)

Color: White

Packaging: 100 m coil

Physical characteristics of the cable:


 Characteristics Value
Center conductor Diameter 1.02+/-0.01mm (18AWG)
Material Copper Clad Steel (CCS)
Conductor insulation Diameter 4.60+/-0.05мм
Centering >=90 %
Shield №1 Material Aluminum foil
Shield density 100%
Thickness 0,12 мм
№2 Number of wires 3/16
Shield density 25%
Material Aluminum
Cable diameter by shield 5,15 мм
Jacket Diameter 6.70±0.10 mm
Material PVC
Dielectric strength of the outer jacket 3000Vac
Color White
Temperature Operating from -20°С to +75°С
Weight Of 1 km of cable 45 kg


Electrical (transmission) characteristics of the cable:

Characteristics Value
Wave impedance 75±3 Ohm
Electrical capacitance 53±2 pF/m
Nominal velocity propagation 83 %
Return loss at 5 - 1000 MHz ≥20 dB
Attenuation, dB/100m (20°С)) 55 MHz 5,25
211 MHz 10
450 MHz 14,43
600 MHz 16,73
870 MHz 20,04
1000 MHz 21,49
Product descriptions are listed according to the available information at the time of publication. Product specifications can be changed without advanced notification. More detailed and exact information can be obtained from the official partners and distributors of LANMASTER.
