Shielded four pairs category 6 cable is designed for digital and analog signals transmission on frequencies below 500 MHz.
The cable comprises four twisted pairs of solid copper conductors are parted with a separator under a single jacket.
Specification
Value
Jacket Color
Jacket Material
LSZH (low some, zero halogen)
Insulation Material
HDPE (high density polyethylene)
Conductor Gauge, single
23 AWG
Conductor Type
Solid
Cable Diameter
7.6 mm
Shield Material
Aluminum polyester foil over 4 pairs
Operating Temperature
-20 ºC to 75 ºC
Cable Length per Box
305 m
Nominal velocity propagation (NVP)
69%
Regulatory Certifications
UL, ETL and 3P Verified to ANSI/TIA/EIA568-D.2-1 Category 6
Regulatory Compliance
TIA/EIA568-D.2-1 Category 6,
ISO/IEC 11801-1:2017,
EN 50288-6-1:2013
Product descriptions are listed according to the available information at the time of publication. Product specifications can be changed without advanced notification. More detailed and exact information can be obtained from the official partners and distributors of LANMASTER.
