TWT UTP cable, 10 pairs, category 5, PVC, 305 meters on a reel

TWT UTP cable, 10 pairs, category 5, PVC, 305 meters on a reel

Product Code: TWT-5UTP10

TWT UTP cable, 10 pairs, category 5, PVC, 305 meters on a reel
Model range

Cable comprises 10 pairs of solid copper conductors.

Cable is unshielded (UTP) and compliance with category 5.

Each conductor is covered with HDPE (high density polyethylene) insulation.

Two conductors are twisted with specially selected step in a single twisted pair. All twisted pairs are grouped in a single bundle with polyethylene tape and enclosed in a PVC jacket.

There is a ripcord under the cable jacket for termination process convenience.

The cable is delivered on reels by 305 meters length. Other construction lengths are available by order.

Specification Value
Jacket Color Blue
Jacket Material PVC
Insulation Material HDPE (high density polyethylene)
Conductor Type Solid
Conductor Gauge 24 AWG
Nominal Velocity Propagation (NVP) 66%
Cable Diameter 7.8 mm
Cable Length per Reel 305 m
Operating Temperature -20 ºC to 75 ºC
Regulatory Certifications UL VERIFIED
Regulatory Compliance TIA/EIA 568.2-E cat. 5; ISO/IEC 11801


Color Coding
Pair Color Pair Color
1 white - blue 6 red - blue
2 white - orange 7 red - orange
3 white - green 8 red - green
4 white - brown 9 red - brown
5 white - grey 10 red - grey
Product descriptions are listed according to the available information at the time of publication. Product specifications can be changed without advanced notification. More detailed and exact information can be obtained from the official partners and distributors of LANMASTER.
