The cable consists of 25 pairs of solid copper conductors. Conductor diameter is 24AWG.
Meets the requirements of category 5e.
Each conductor is enclosed in HDPE (high-density polyethylene) insulation.
Two conductors, twisted with a specially selected step, make up one twisted pair. The twisted pairs are assembled around the central strength member and enclosed in a common polyethylene (PE) jacket.
To facilitate cable termination, a rip cord is included under the jacket.
The cable is supplied on 305 meters drums. Other construction lengths can be supplied on request.
Physical characteristics of the cable:
Characteristic
Value
Jacket color
Black
Jacket material
PE (Polyethylene)
Insulation material
HDPE (High Density Polyethylene)
Conductor diameter
24 AWG
Conductor Type
Solid
Insulation thickness
0,24 mm
Cable diameter
12,5 mm
Cable diameter
CMX (outdoor use cable)
NVP
66%
Frequency range
1-100 MHz
Operating temperature range
- 40°C to +75 °C
Number of meters per drum
305 m
Laboratory certification
UL, ETL VERIFIED
Compliant with TIA/EIA 568-A cat.5 standards; ISO/IEC 11801; EN 50173
Support for the following applications:
Speech
Т1
10BASE-T, 100BASE-T
Token Ring 4/16 Mb/s
АТМ 155 Mb/s, TP-PMD 100 Mb/s
100VG-AnyLAN
100 Mbps CDDI
Color coding:
Pair 1 White — Blue
Pair 13 Black — Green
Pair 2 White — Orange
Pair 14 Black — Brown
Pair 3 White — Green
Pair 15 Black — Grey
Pair 4 White — Brown
Pair 16 Yellow — Blue
Pair 5 White — Grey
Pair 17 Yellow — Orange
Pair 6 Red — Blue
Pair 18 Yellow — Green
Pair 7 Red — Orange
Pair 19 Yellow — Brown
Pair 8 Red — Green
Pair 20 Yellow — Grey
Pair 9 Red — Brown
Pair 21 Purple — Blue
Pair 10 Red — Grey
Pair 22 Purple — Orange
Pair 11 Black — Blue
Pair 23 Purple — Green
Pair 12 Black — Orange
Pair 24 Purple — Brown
Pair 25 Purple — Grey
Electrical characteristics of the cable:
Characteristic
Value
Impedance
100 +/- 15 Ohm
Maximum capacitance
17.1 nF/305m
Conductor resistance
28.6 Ohm/305m
Unbalance resistance
5%
Pair capacitance to ground unbalance
330 pF/100m
Skew delay
45 ns/100m
Nominal velocity propagation rate
66%
Product descriptions are listed according to the available information at the time of publication. Product specifications can be changed without advanced notification. More detailed and exact information can be obtained from the official partners and distributors of LANMASTER.
Model range (1)
Code
Name
TWT-5EUTP25-OUT
TWT UTP cable, 25 pairs, Cat. 5e, for outdoor installation, 305 meters per drum
