Multi-pair non-shielded cable is intended for transmitting data, telephone and television signals at frequencies up to 100 MHz. The cable consists of 25 pairs of solid copper conductors. Outer jacket: LSZH. Conductor diameter is 24 AWG.
Each conductor is enclosed in HDPE (high-density polyethylene) insulation. Two conductors, twisted with a specially selected step, make up one twisted pair.
Twisted pairs are collected around the central element and enclosed in a common LSZH (low-smoke, zero-halogen) jacket.
To facilitate cable termination, a rip cord is included under the jacket.
The cable is supplied on 305 meters drums. Other construction lengths can be supplied on request.
Physical characteristics of the cable:
Characteristic
Value
Jacket color
White
Jacket material
LSZH (low-smoke, zero-halogen)
Insulation material
HDPE (High Density Polyethylene)
Conductor diameter
24 AWG
Conductor Type
Solid
Insulation thickness
0,20+/-0,05 mm
Cable diameter
12,0+/-1,0 mm
Frequency range
1-100 MHz
Operating temperature range
-20 °C / +75 °C
Number of meters per drum
305 m
Laboratory certification
UL
Compliant with TIA/EIA 568-A cat.5 standards; ISO/IEC 11801; EN 50173
Support for the following applications:
Speech
Т1
10BASE-T, 100BASE-T
Token Ring 4/16 Mb/s
ATM 155 Mb/S, TP-PMD 100 Mb/s
100 VG-AnyLAN
100 Mbps CDDI
Electrical characteristics of the cable:
Characteristic
Value
Impedance
100+/-15 Ohm
Unbalance resistance
5%
Pair capacitance to ground unbalance
330pF/100m
Skew delay
45ns/100m
