The cable consists of 25 pairs of solid copper conductors. Conductor diameter is 24AWG. Each conductor is enclosed in HDPE (high-density polyethylene) insulation.
Two conductors, twisted with a specially selected step, make up one twisted pair. Twisted pairs are assembled around the central element, wrapped in a plastic film and enclosed in a common PVC jacket.
To facilitate cable termination, a rip cord is included under the jacket.
Characteristic
Value
Jacket color
Blue
Jacket material
PVC (polychlorinated vinyl chloride)
Insulation material
HDPE (High Density Polyethylene)
Conductor diameter
24 AWG
Conductor Type
Solid
Cable diameter
12 mm
Fire safety rating
CM (general use cable)
Operating temperature range
-20 °C / +75 °C
Impedance
100 Ohm
Number of meters per drum
305 m
Color coding:
Pair 1 White — Blue
Pair 13 Black — Green
Pair 2 White — Orange
Pair 14 Black — Brown
Pair 3 White — Green
Pair 15 Black — Gray
Pair 4 White — Brown
Pair 16 Yellow — Blue
Pair 5 White — Grey
Pair 17 Yellow — Orange
Pair 6 Red — Blue
Pair 18 Yellow — Green
Pair 7 Red - Orange
Pair 19 Yellow — Brown
Pair 8 Red — Green
Pair 20 Yellow — Gray
Pair 9 Red — Brown
Pair 21 Purple — Blue
Pair 10 Red — Grey
Pair 22 Purple — Orange
Pair 11 Black — Blue
Pair 23 Purple — Green
Pair 12 Black — Orange
Pair 24 Purple — Brown
Pair 25 Purple — Gray
Product descriptions are listed according to the available information at the time of publication. Product specifications can be changed without advanced notification. More detailed and exact information can be obtained from the official partners and distributors of LANMASTER.
