UTP cable, two pairs, category 5e, LSZH

UTP cable, two pairs, category 5e, LSZH

Product Code: TWT-5EUTP2-LSZH

UTP cable, two pairs, category 5e, LSZH
Model range

Two pairs cable is a budget solution for voice, fire alarm, and security cabling, connection of xDSL modems, and Ethernet network (10Base-T and 100Base-T which use two pairs for connection) cabling.

Specification Value
Jacket Color Grey
Jacket Material LSZH (low smoke, zero halogen)
Insulation Material HDPE (high density polyethylene)
Conductor Gauge, single 24 AWG
Conductor Type Solid
Cable Diameter 4,5 mm
Operating Temperature -20 ºC to +75 ºC
Cable Length per Box 305 m
Nominal Velocity Propagation (NVP) 67%
Regulatory Certifications ETL VERIFIED
Regulatory Compliance TIA/EIA 568-D.2 cat. 5e
Product descriptions are listed according to the available information at the time of publication. Product specifications can be changed without advanced notification. More detailed and exact information can be obtained from the official partners and distributors of LANMASTER.
