TWT UTP cable, for patch-cords, 1 pair, cat. 5e, PVC, 305 meters, grey

TWT UTP cable, for patch-cords, 1 pair, cat. 5e, PVC, 305 meters, grey

Product Code: TWT-5EUTP1PT-GY

TWT UTP cable, for patch-cords, 1 pair, cat. 5e, PVC, 305 meters, grey
Model range

The cable consists of one pair of stranded copper conductors.
Conductor diameter is 24AWG.
Each conductor is insulated with HDPE (high density polyethylene).
Two conductors twisted with a specially selected step and forming one twisted pair are enclosed in a common PVC jacket.

Conductor Material Copper
Type 7 wire / 0.18 ± 0.01 mm
Insulation Material
 HDPE
Thickness 0.19 mm
Diameter 0.92 ± 0.05 мм
Jacket Material PVC
Thickness 0.50 mm
Diameter 2.8 ± 0.20 mm
Wave impedance
 max. 116 Ohm/km at 20℃
Insulation Resistance
 min. 10 MOhm/m at 20℃
Product descriptions are listed according to the available information at the time of publication. Product specifications can be changed without advanced notification. More detailed and exact information can be obtained from the official partners and distributors of LANMASTER.

Model range (1)

Code Name
TWT-5EUTP1PT-GY TWT UTP cable, for patch-cords, 1 pair, cat. 5e, PVC, 305 meters, grey Add to list
