TWT UTP cable, 4 pairs, XL series, category 5е, PVC

TWT UTP cable, 4 pairs, XL series, category 5е, PVC

Product Code: TWT-5EUTP-XL

TWT UTP cable, 4 pairs, XL series, category 5е, PVC
Model range

Unshielded four pairs category 5e cable is designed for digital and analog signals transmission on frequencies below 100 MHz

The cable comprises four twisted pairs of solid copper conductors under a single jacket.

Specification
 Value
Jacket Color Grey
Jacket Material PVC (polyvinyl chloride)
Insulation Material HDPE (high density polyethylene)
Conductor Type Solid
Conductor Diameter 24 AWG
Cable Diameter 5.0 mm
Operating Temperature -20 ºC to 75 ºC
Cable Length per Box 305 m
Nominal velocity propagation (NVP) 67%
Regulatory Certifications UL, ETL VERIFIED
Regulatory Compliance TIA/EIA 568-D.2 cat. 5E
Product descriptions are listed according to the available information at the time of publication. Product specifications can be changed without advanced notification. More detailed and exact information can be obtained from the official partners and distributors of LANMASTER.
