TWT UTP cable, 4 pairs, category 5e, LSZH, 305 m, white

TWT UTP cable, 4 pairs, category 5e, LSZH, 305 m, white

Product Code: TWT-5EUTP-LSZH

TWT UTP cable, 4 pairs, category 5e, LSZH, 305 m, white
Model range

Unshielded four pairs category 5e cable is designed for digital and analog signals transmission on frequencies below 100 MHz.

The cable comprises four twisted pairs of solid copper conductors under a single jacket. There is a ripcord under cable jacket for termination process convenience.
The cable jacked is made from polymer compound with low smoke and gases emission which fire retardant for group cabling as stated in GOST IEC 60332-3-22-2011 and GOST IEC 61034-2-2011.

Box dimensions (DxWxH) – 352 х 196 х 352 mm.

Box weight – 11.8 kg.

Specification Value
Jacket Color White
Jacket Material LSZH
Insulation Material HDPE (high density polyethylene)
Conductor Type Solid
Conductor Gauge 24 AWG
Cable Diameter 5.0 ± 0.5 mm
Nominal velocity propagation (NVP) 66 % at 100 MHz
Cable Length per Box 305 m
Operating Temperature -20 ºC to 75 ºC
Regulatory Certifications ETL VERIFIED
Regulatory Compliance

TIA/EIA 568-D.2 cat. 5E,

ISO/IEC 11801-1:2017,

EN 50173
Product descriptions are listed according to the available information at the time of publication. Product specifications can be changed without advanced notification. More detailed and exact information can be obtained from the official partners and distributors of LANMASTER.
