TWT FTP cable, 50 pairs, category 5e, PVC, 305 meters on a reel
Model range

The multipairs shielded cable is designed for transmission of data, voice and CCTV signals on frequencies below 100 MHz. The cable comprises 50 pairs of solid copper conductors. Outer jacket is PVC.

Each conductor is covered with HDPE (high density polyethylene) insulation. Two conductors are twisted with specially selected step in a single twisted pair.

The twisted pairs are gathered around a core element and covered with a single PVC jacket.

There is a ripcord under the cable jacket for termination process convenience.

The cable is delivered on reels by 305 meters length. Other construction lengths are available by order.

Specification

Value

Jacket Color

Blue

Jacket Material

PVC (polyvinyl chloride)

Insulation Material

HDPE (high density polyethylene)

Conductor Type

Solid

Conductor Gauge

24 AWG

Nominal Velocity Propagation (NVP)

66%

Cable Diameter

8.3 mm

Cable Length per Reel

305 m

Operating Temperature

-20 ºC to 75 ºC

Regulatory Certifications

UL

Regulatory Compliance

TIA/EIA 568.2-D cat. 5; ISO/IEC 11801; EN50173
Product descriptions are listed according to the available information at the time of publication. Product specifications can be changed without advanced notification. More detailed and exact information can be obtained from the official partners and distributors of LANMASTER.
