The cable comprises 10 pairs of solid copper conductors. It is compliance with category 5e.
Each conductor is covered with HDPE (high density polyethylene) insulation. Two conductors are twisted with specially selected step in a single twisted pair.
The twisted pairs are gathered around a filled rope, wrapped in laminated foil and covered with a single PE (polyethylene) jacket.
There is a ripcord under the cable jacket for termination process convenience and a drain wire for continuous grounding under the foil layer.
The cable jacked is marked with length tags in meters.
The cable is delivered on reels by 305 meters length. Other construction lengths are available by order.
Specification
Value
Jacket Color
Black
Jacket Material
PE (polyethylene)
Insulation Material
HDPE (high density polyethylene)
Conductor Type
Solid
Conductor Gauge
24 AWG
Nominal Velocity Propagation (NVP)
66%
Cable Diameter
8.7 mm
Cable Length per Reel
305 m
Operating Temperature
-20 ºC to 75 ºC
Regulatory Certifications
UL
Regulatory Compliance
TIA/EIA 568.2-D cat. 5; ISO/IEC 11801; EN50173
Color Coding
Pair
Color
Pair
Color
1
white - blue
6
red - blue
2
white - orange
7
red - orange
3
white - green
8
red - green
4
white - brown
9
red - brown
5
white - grey
10
red - grey
Product descriptions are listed according to the available information at the time of publication. Product specifications can be changed without advanced notification. More detailed and exact information can be obtained from the official partners and distributors of LANMASTER.
Model range (1)
Code
Name
TWT-5EFTP10-OUT
TWT FTP cable, 10 pairs, category 5e, outdoor, 305 meters on a reel
