TWT FTP cable, 4 pairs, category 5е, LSZH

TWT FTP cable, 4 pairs, category 5е, LSZH

Product Code: TWT-5EFTP-LSZH

TWT FTP cable, 4 pairs, category 5е, LSZH
Model range

Shielded four pairs category 5e cable is designed for digital and analog signals transmission on frequencies below 100 MHz.

The cable comprises four twisted pairs of solid copper conductors with overall foil shield under a single jacket.

Specification Value
Jacket Color White
Jacket Material LSZH (low some, zero halogen)
Insulation Material HDPE (high density polyethylene)
Conductor Gauge, single 24 AWG
Conductor Type Solid
Cable Diameter 5.9 mm
Shield Material Aluminum polyester foil over 4 pairs
Operating Temperature -20 ºC to 75 ºC
Cable Length per Box 305 m
Nominal velocity propagation (NVP) 66%
Regulatory Certifications ETL VERIFIED
Regulatory Compliance

TIA/EIA 568-D.2 cat. 5E,

ISO/IEC 11801-1:2017;

EN 50173
Product descriptions are listed according to the available information at the time of publication. Product specifications can be changed without advanced notification. More detailed and exact information can be obtained from the official partners and distributors of LANMASTER.
