Probe and tone generator kit, TPK-50

Probe and tone generator kit, TPK-50 LAN-TPK-50: specifications, description, purpose and use in structured cabling, data center and LANMASTER infrastructure projects.
Withdrawn from sale
Replacement LAN-TST-TPK-50
LAN-TPK-50

The LAN-TPK-50 test kit consists of a tone generator and an inductive probe (receiver).

The kit is used to:

  • Cable line tracing.
  • Checking the polarity of the phone line.
  • Checking line continuity.
  • Sending a tone into the line.

The TPK-50 can work with various types of cables: twisted pair, single wire, coaxial cable, or any other type of wire.

The generator allows you to produce two types of tone signals. This allows you to search for two lines at the same time with generators set to different tones. Tone selection is done by a microswitch located inside the generator case. The generator is equipped with one RJ-12 and two crocodile clips for line connection.

The probe is equipped with a powerful speaker with adjustable sensitivity and a terminal for connecting a test headset.

The kit comes in a sturdy, compact case for easy carrying. Package includes:

  • Probe (receiver),
  • Generator (sender),
  • User manual,
  • Carrying case,
  • Packing box.

Attention!!! Batteries are not included in the tool kit.

Frequently Asked Questions

Is the LAN-TPK-50 model still manufactured?

No, production of the LAN-TPK-50 model has been discontinued. The current replacement with the same purpose is the LAN-TST-TPK-50 model.

What was the LAN-TPK-50 kit used for?

This tone generator and probe receiver kit located and identified a cable in a bundle of wires without disconnecting it.

Why is the tone heard on several wires in a bundle at once, not only the right one?

This is normal when the probe is held near a bundle — crosstalk makes the signal audible on neighboring wires too. To pinpoint the right wire, touch the probe tip directly to the bare conductor: on the correct wire the tone becomes noticeably louder than on the others.

Didn’t find an answer to your question?

Package dimensions and weight

Single item

Product code Unit length × width × height (mm) Weight (kg) Volume (m3)
LAN-TPK-50 pcs 260 × 40 × 120 0.23 0.001248

Package

Product code Unit length × width × height (mm) Weight (kg) Volume (m3)
LAN-TPK-50 box 510 × 260 × 270 7.2 0.035802
