TWT UTP cable, 4 pairs, category 5е, outdoor, 305 m

TWT UTP cable, 4 pairs, category 5е, outdoor, 305 m

Product Code: TWT-5EUTP-OUT

TWT UTP cable, 4 pairs, category 5е, outdoor, 305 m
Model range

The cable is suitable for outdoor installation. Polyethylene jacket reliable protects cable from harsh environment, does not degrade under Solar radiation, and allows operational temperatures from 40oС to +75 oС.

Four pairs UTP cable has a following design:
Conductor is a solid 24 AWG wire with HDPE (high density polyethylene) insulation.

Two conductors comprise a single twisted pair. The cable consists of four pairs, each pair twisted with different but specially selected step.

The cable jacket has per meter length marks.

Specification Value
Jacket Color Black
Jacket Material PE (polyethylene)
Insulation Material HDPE (high density polyethylene)
Conductor Gauge, single 24 AWG
Conductor Type Solid
Cable Diameter 4.8 mm
Operating Temperature -20 ºC to +75 ºC
Cable Length per Box 305 m
Nominal velocity propagation (NVP) 66%
Regulatory Certifications

UL, ETL VERIFIED
Regulatory Compliance

TIA/EIA 568-D.2 cat. 5E,

ISO/IEC 11801-1:2017;

EN 50173

The cable has better transmission characteristics then defined in standards for 1-100 MHz frequency band.

Product descriptions are listed according to the available information at the time of publication. Product specifications can be changed without advanced notification. More detailed and exact information can be obtained from the official partners and distributors of LANMASTER.
