LANMASTER UTP cable, 4 pairs, cat. 5E, 350 MHz, LSZH, 305 m
Product Code: LAN-5EUTP-LSZH-xx
LANMASTER UTP cable, 4 pairs, cat. 5E, 350 MHz, LSZH, 305 m
The cable consists of 4 pairs of single copper conductors.
The diameter of the conductor is 24AWG.
Each conductor is put in HDPE (high density polyethylene) insulation.
Two conductors stranded with a specially selected step make up one twisted pair.
4 twisted pairs are wrapped with a LSZH (low smoke, zero halogen) sheath.
There is a rip cord under the sheath to facilitate cable partition.
Characteristic of the cable:
Characteristic Value Type of conductor Solid Conductor Diameter 24 AWG Insulation Type HDPE (High Density Polyethylene) Type of sheath LSZH Sheath color Orange Cable diameter 4,9 mm Nominal velocity propagation 71% Operating temperature range to + 75 °C Certified by the laboratory 3P и ETL Complies with TIA/EIA 568-B.2 cat. 5E Meters in a box 305 m Color coding Pair 1 "blue/white-blue";
Cable transfer characteristics:
Frequency Attenuation NEXT ACR PS.NEXT PS.ACR ELFEXT PS.ELFEXT Return Loss 1 2.4 68.3 65.9 66.3 63.9 63.8 60.8 20 4 4.9 59.3 54.4 57.3 52.4 51.7 48.7 23 8 6.9 54.8 47.9 52.8 45.9 45.7 42.7 24.5 10 7.8 53.3 45.5 51.3 43.5 43.8 40.8 25 16 9.8 50.3 40.5 48.3 38.5 39.7 36.7 25 20 11.2 48.8 37.6 46.8 35.6 37.8 34.8 25 25 12.5 47.3 34.8 45.3 32.8 35.8 32.8 24.2 31.25 14 45.9 31.9 43.9 29.9 33.9 30.9 23.3 62.5 20.4 41.4 21 39.4 19 27.8 24.8 20.7 100 26.4 38.3 11.9 36.3 9.9 23.8 20.8 19 155 33.7 35.5 1.8 33.5 0 20 17 17.4 200 38.9 33.8 -/- 31.8 -/- 17.7 14.7 16.4 240 43.2 32.6 -/- 30.6 -/- 16.2 13.2 15.7 300 49.2 31.2 -/- 29.2 -/- 14.2 11.2 14.9 350 53.9 30.1 -/- 28.1 -/- 12.9 9.9 14.3
Product descriptions are listed according to the available information at the time of publication. Product specifications can be changed without advanced notification. More detailed and exact information can be obtained from the official partners and distributors of LANMASTER.
